Main technical specifications
1.Experimental force（Seven levels in total）
4.903N(0.5kgf) 9.807N(1.0kgf)
19.61N(2.0kgf) 24.52N(2.5kgf)
29.42N(3.0kgf) 49.03N(5.0kgf)
98.07N(10kgf)
2.Measuring range 5-3000HV
3.Optical system
Objective lense: 10X,40X
Eyepiece:12.5X
Total magnification factor: 125X, 500X
Measuring range: 10X-1.0mm, 40X-0.2mm
4.Measurement accuracy: ±0.01um
5.Duration Time 0-99s
6.Maximum allowable sample height: 130mm,
Distance from the center of the pressure head to the machine wall: 110mm
7.Coordinate test bench size: 100×100mm
8.Coordinate test bench travel: 25×25mm
9.Coordinate test bench division value : 0.01mm
10.Light source: 3.4V/1W
11.Language Chinese, English
12.Power Supply: 220V, 50Hz(110V/60Hz)
13.Whole machine power consumption: ≤50W
14.External dimension: 486×337×657( length X width X height)
15.Weight: 88kg
